Cartridge Filling Machines

SCHWERDTEL filling machines can process all pasty products with a visible reduction of filling costs. An air-free, accurate, quick and economical filling is possible due to Schwerdtel know-how.

The ease of operation of the machines contributes to the profitability; even personnel not experienced with our machines require only a short training to get used to operation and maintanance.
It goes without saying that we will be pleased to offer you a filling unit for your special cartridge and corresponding plunger.


Cartridge Filling Machines



SD-H Version 1 Semi-Automatic Cartridge Filling and Closing Machine

For the semi-automatic filling of sealants, adhesives and grease into plastic, fibre or aluminium cartridges with a filling volume from 100 to 500 ml.

An output rate of up to 15 cartridges per minute can be reached.


SD-H Version 2 Semi-Automatic Cartridge Filling and Closing Machine

For the semi-automatic filling of sealants, adhesives and grease into plastic, fibre or aluminium cartridges with a filling volume from 500 to 1000 ml.

An output rate of up to 15 cartridges per minute can be reached.

Picture shows version for low viscous products with vertical plunger inserting unit.


S8-A/12 Fully Automatic Cartridge Filling and Closing Machine

High quality at low cost.

By using an pneumatic driven dosing unit, depending on material viscosity and product infeed pressure, an output rate of up to 35 cartridges per minute can be reached.


S8-A/20 Fully Automatic Cartridge Filling and Closing Machine

High quality at low cost.

By using an electric dosing unit, depending on material viscosity and product infeed pressure, an output rate of up to 38 cartridges per minute can be reached.


S8-2A/P Fully Automatic Cartridge Filling and Closing Machine

For the automatic filling of pasty products into plastic, aluminium or cardboard cartridges.

By using two pneumatic dosing units, depending on material viscosity and product infeed pressure, an output rate of up to 70 cartridges per minute can be reached.


S8-2A/E Fully Automatic Cartridge Filling and Closing Machine

For the automatic filling of pasty products into plastic, aluminium or cardboard cartridges.

By using two electric dosing units, depending on material viscosity and product infeed pressure, an output rate of up to 80 cartridges per minute can be reached.


S8-B/12 Fully Automatic Cartridge Filling and Closing Machine


The cartridge filling machine provides fully-automatic, precise and airfree filling of pasty products such as sealants, adhesives and others, into cartridges.

The filling machine can handle plastic or cardboard cartridges with and without nozzles.

By using an electrically driven dosing unit, depending on material viscosity and product infeed pressure, an output rate of up to 52 cartridges per minute can be reached


S8-B/22 Fully Automatic Cartridge Filling and Closing Machine

For the filling and closing of aluminum cartridges, including silicagel capsule inserting and seaming of the cartridge.

Depending on material viscosity and product infeed pressure, an output rate of up to 33 cartridges per minute can be reached.


S8-2B Fully Automatic Cartridge Filling and Closing Machine

By using two electric dosing units and two filling stations, depending on product, an output rate of up to 80 cartridges per minute can be reached.


S8-VA Vertical Fully Automatic Cartridge Filling and Closing Machine

For the automatic vertical filling of pasty products into plastic, aluminium or cardboard cartridges.


Depending on installed type of dosing unit, the material viscosity and product infeed pressure, an output rate of up to 35 cartridges per minute can be reached.


S8-VDH Vertical Semi-Automatic Cartridge Filling and Closing Machine


For the filling of printing inks cartridges.

An output rate of up to 6-10 cartridges per minute can be reached.

Fully automatic, air free plungering of cartridges, spraying station for anti drying agent, before and after the filling, (inner wall of cartridge, printing ink surface) can be implemented optional.


S8-VD Vertical Fully-Automatic Cartridge Filling and Closing Machine for Printing Ink


For the filling of printing inks cartridges.

An output rate of up to 20 cartridges per minute can be reached.

Fully automatic, air free plungering of cartridges, spraying station for anti drying agent, before and after the filling, (inner wall of cartridge, printing ink surface) can be implemented optionally.

If you require a case packer for this line, we will be pleased to offer you a customized solution.
